Dual-mode Magnetic Elastomer Moves Like a Robot and Self-Erases After Finishing Task

Magnetic Elastomer Powers Robots That Self-Erase
New magnetic elastomer moves under one magnetic field and rapidly degrades under another for soft robots and secure devices.

Researchers from Seoul National University have developed a new smart material that can both perform tasks and remove itself afterward.

The material is designed to respond to magnetic fields in two different ways. It can move and change shape during operation, and later break down when no longer needed.

The development addresses a growing challenge in both soft robotics and advanced electronics. Many modern robotic systems are being designed to operate in confined, sealed, or hazardous environments. These include underground facilities, industrial pipelines, hazardous areas, and areas with difficult human access.

Once these devices complete their missions, retrieving them can be expensive or impossible. Equipment left behind can create contamination risks, damage sensitive systems, or expose confidential information. Researchers have been searching for materials that can perform a task and then safely disappear when the mission ends.

Self-erasing Magnetic Elastomer

The new material is a silicone-based magnetic elastomer. An elastomer is a flexible material that can stretch and return to its original shape. The researchers embedded iron oxide nanoparticles inside the silicone structure.

These nanoparticles play two important roles. Under a direct-current magnetic field, they help the material move and change shape. Under an alternating-current, magnetic field operating at gigahertz frequencies, they generate heat.

READ ALSO: Rohde & Schwarz Unveils Versatile EMI Test Receivers at EMV2025, Enabling Smarter Investment Strategies

This dual function allows the same material to handle both motion and degradation. No separate control system is needed for each task. The entire process can be managed remotely using magnetic fields.

During testing, the elastomer demonstrated strong motion under DC magnetic fields. It underwent shape changes and soft actuation, which is the controlled movement often used in soft robots. This allows the material to bend, deform, and perform mechanical tasks.

The degradation process is activated differently. When exposed to an AC magnetic field in the gigahertz range, the nanoparticles rapidly generate localized heat. The temperature rises above 200 degrees Celsius in less than one second.

This intense heating triggers the breakdown of the silicone structure. Researchers found that chemical bonds known as silicon-oxygen(Si-O) bonds are broken during the process. As these bonds are destroyed, the material quickly degrades.

Importantly, the elastomer remains highly flexible before degradation begins. Tests showed that it can stretch to more than 460 percent of its original length before breaking. This level of flexibility is important for soft robotic applications that require repeated bending and movement.

The research team also demonstrated several practical uses. One demonstration involved a soft robotic system that could move under magnetic control and later degrade when activated. Another example used the material as a degradable electronic switch capable of selectively controlling LED operation.

These demonstrations highlight possible applications in both robotics and electronics. In robotics, the material could help create devices that enter clogged pipes, perform maintenance tasks, and then disappear after completing their work. This would remove the need for retrieval operations.

WATCH ALSO: A Brazilian skateboarder set a world record as he turned 22-storey skyscraper into giant ramp

In electronics, the technology offers a potential solution for secure hardware. Devices built with the material could physically erase themselves after use, reducing the risk of sensitive information being recovered. This feature may be valuable for security, defense, and data protection applications.

The research also simplifies system design. Existing technologies often require different triggers or separate components for movement and degradation. By combining both functions into a single material platform, engineers can reduce complexity and improve operational efficiency.

As soft robots become more common across healthcare, industrial inspection, environmental monitoring, and infrastructure maintenance, materials that support their full life cycle are important. The new magnetic elastomer provides a practical way to control both performance and end-of-life behavior with a single remote stimulus.

The study presents a new direction for smart materials designed not only to function effectively but also to disappear once their mission is complete. As researchers continue refining the technology, it may support a new generation of robotic and electronic systems built for environments where retrieval is difficult or unnecessary.
